Features

Product features and usage range:
Large conveying capacity, stable and reliable operation, convenient maintenance, and low noise
Flexible wiring, capable of long-distance transportation, and adjustable conveying speed to meet various process requirements
performance parameter

● Pitch: 100mm, 125mm, 160mm, 200mm, 250mm, 315mm, 400mm

Width: 160mm3000mm
Operating speed: between 0.5-20m/min
Maximum traction force: 3KN-150KN
Maximum working length: 200m
Maximum climbing height: 20m

System composition

● Drive device
● Tensioning device
● Rack
● Chain
Chain plate: scale plate or flat plate
Applicable scope
◇ Flat conveyor is mainly used for body adjustment, vehicle and zero height assembly, etc
◇ Heavy scale conveyor is mainly used for conveying castings
◇ Light scale conveyor for conveying stamping waste
